Bluetooth Rechargeable Badge Beacon C3 Series

Bluetooth Rechargeable Badge C3

The C3 Bluetooth Rechargeable Badge is designed for personal safety and effective management. With C3 Bluetooth Rechargeable Badge IP67 waterproof rating and sleek ID card design, C3 beacon perfect for various applications, including personnel management and emergency situations

DESCRIPTION

Bluetooth Rechargeable Badge Beacon C3
Bluetooth Low Energy 4.0/5.0
Ultra-low power consumption chipset Nordic nRF52 series
Support iBeacon/ Eddystone at the same time
Logo and color customizable
Provide with your own configuration
100% configuratble parameters via App (Both Android & ios)

C3 rechargeable Card Beacon is waterproof & ID card design Beacon with ultra low power chipset Nordic nRF52 series and BLE 5.0 technology.

C3 rechargeable badge also have variety of NFC/RFID standard support.
It is in credit card size and can be easily hanged in a lanyard. It has very strong signal, it is designed for personnel management, SOS, and indoor location-based service such as hospital patient management solution, staff management, SOS solution.

C3 Bluetooth ID badge broadcasts 2.4GHz radio signals at regular and adjustable intervals, its parameters are configurable by Android & iOS App and KGateway.

FEATURES

Smart magnetic charging
External button for SOS
Multiple RFID/NFC standard support

Wearable & credit-card sized design
IP67 dust & water resistance
Up to 984 ft (300 m) broadcast distance

Rechargeable badge

Ultra-low power consumption chipset

Support 5url broadcasting

Firmware update Over The Air (OTA)

Logo and color customizable

Provided with your own configuration

100% Configurable Parameters via app (Android & iOS)

DOWNLOAD

Rechargeable ID card
NFC/RFID tag optional
Compatible with iBeacon, Eddystone (UID, URL, TLM) and KSensor at the same time.
All the parameters of this product can be modified via configure APP or KGateway.

product applications

product details

Size	86mm56mm5.4mm
Material	ABS
Color	White (colors customizable)
Weight	24g (with battery)
Battery capacity	400mAh rechargeable battery
Battery life	16 months per charge (2 hours for fully recharge) * Base on Adv Interval 1000ms and TX power 0dBm, no Coded PHY
IP rating	IP67 waterproof
Working temperature	-20℃ ~+60℃
Working humidity	0 ~ 99% RH
Switch	External Button
Sensor	Accelerometer Sensor (optional)
Config APP	KBeaconPro
Bluetooth Version	BLE 5.0/ BLE 4.x
OTA	Yes
TX power	-40~+4dBm (C3P: -40dBm~+8dB)
Broadcast Interval	100ms ~ 40000ms
Transmit Range	C3: >80 meters; C3P: BLE4.x >80 meters; BLE5.0 Coded PHY long range 300 meters *Base on installing in open space

Type(channel)	Item	Default settings
Ksensor (off)	Battery level Temperature Tamperproof alert	Actual measurements
iBeacon (on)	UUID Major/Minor Measured power	Not broadcast by default
Eddystone UID/URL/TLM (off)	Instance ID Namespace ID Measured power	Not broadcast by default
System	MAC address Model ID Battery percent Software version	Assigned at factory 31 0%~ 100% 6.x
Password	Password	0000000000000000(default)
Connectable mode	Connectable or not	YES
